AR B302

AR B302 is  a compound which consists of polyols, surfactants, catalysts, and flame retardant , mixture of HFC-245fa as blowing agent in a special ratio.
-The foam has good thermal insulation property, light weight, high compression strength and flame retardant and other advantages. Widely used in the process of all kinds of insulation work such as: building external wall, cold storage, tanks, large pipes etc.

INQUIRE NOW

"*" indicates required fields

Category:
Technical Data Sheet



Liquid Components Properties

Property Blend Polyols Isocyanate
Colour Light yellow to brown liquid Brown
Hydroxyl value         mgKOH/g 280-360 /
Viscosity @ 25°C           mPa.S 200-400 200-250
Specific gravity  @ 20°C     g/ml 1.15-1.25 1.20-1.25
Storage temperature            ℃ 10-25 10-25
Shelf life 6 months 12 months

Technical Condition

Blend Polyols: Isocyanate MDI 100:110-130
Raw material temperature     ℃ 18-22
Moulding temperature       ℃ 30-40

Technology and Reactivity  (the exact value varies depending on processing conditions）

Items Cup Test High Pressure machine
Cream time    s 10-40 8-30
Gel time      s 100-200 80-160
Free density  kg/m3 25-30 24-29

Foam Performance

Moulding density ASTM D1622 ≥40kg/m3
Close-cell rate ASTM D2856 ≥90%
Thermal conductivity（15℃） ASTM C518 ≤22mW/(m.K)
Compression strength ASTM D 1621 ≥140kPa
Dimensional stability  24h  -20℃

24h  100℃

 ASTM D2126 ≤1%

≤1.5%
Flame Resistance DIN 4102 B3

Package

220kg/drum or 1000kg/IBC.
